Manhattan HDMI přepínač, 1080p 4-Port HDMI Multiviewer Switch, černá

Cable/adaptor specification:Adapter

Twoja cena:

Dostępność: Zazwyczaj 14 dni

Kod:

254928

P/N:

207881

Gwarancja:

24 Mies.

Producent:

Manhattan

Przedstawiciel w UE:

EAN:

766623207881

Szczegóły

Switch with Four Inputs on One Display, Video Bandwidth Amplifier, IR Remote Control, Black

Share up to four HDMI Audio/Video sources on one display at the same time or one at a time
Multiviewer function supports four customizable modes: Full Screen and three variations of Combo Mode with seamless switching between sources
Supports 1080p resolution as well as HD 3D video and Deep Color (36-bits/pixel)
Integrated video bandwidth amplifier
Supports LPCM, DTS Digital, DTS-HD Master Audio and Dolby TrueHD audio
Supports Stereo, Coaxial and Toslink Audio output for connection to amplifier or receiver for the best sound quality
Supports source switching via IR remote control or manual switching with the push of a button
A flexible Audio/Video solution for conference rooms (when sharing ideas and data), digital signage (reducing space and cost needed for multiple displays), security and other applications
Works with PlayStation and Xbox game systems, Blu-ray players, set-top boxes, satellite receivers and more
Fully HDCP compliant
AC powered with Plug and Play installation; no special setup or remote required
Plug-and-play installation
Gold-plated contacts for corrosion-free connections
Three-year warranty

TECHNICAL SPECIFICATIONS

Standards and Certifications	- HDMI 1.3 - HDCP 1.4a - CE - FCC - RoHS2
Package Contents	- 1080p 4-Port HDMI Multiviewer Switch - IR Remote Control - Power Adapter - Quick Instruction Guide
General
Source-to-switch range	up to 15 m (49 ft.)
Switch-to-display range	up to 15 m (49 ft.)
Power	12 VDC @ 2 A; AC power adapter: 0.9 m (2.9 ft.)
Remote battery (included)	CR2025 3 V lithium cell
Connections
Connections	One HDMI female, 19-pin (output) Four HDMI female, 19-pin (input) One Stereo female, 3.5 mm (output) One Coaxial female, S/PDIF (output) One Toslink female (output) One USB, Mini-B (input) factory use only One 12 VDC power female, OD 5.5 mm / ID 2.1 mm (input)
Signal Input/Output
Input video signal	400 - 600 mV
Input DDC signal	5 V p-p (TTL)
Maximum single-link range	2.25 Gbps and 1080p resolution
Output video	HDMI 1.3, HDCP 1.4a
Frequency	2.25 Gbps / 225 MHz
Supported Video Resolutions
DTV/HDTV	480i/480p/576i/576p/720p/1080i/1080p
Physical
LED indicators	power and port connection
Power adapter	12 VDC / 2A; 0.9 m (2.9 ft.)
Dimensions	213 x 100 x 25 mm (8.4 x 3.9 x 1 in.)
Weight	0.46 kg (1 lbs.)
Housing	metal
Operating Environment
Operation Temperature	0 – 40°C (32 – 104°F)
Storage Temperature	-20 – 60°C (-4 – 140°F)
Humidity (noncondensing)	0 – 96%
